Special Features
Accuracy: ±1.0% of rate;±0.5% of rate;±0.25% of rate
Body material: Duplex 2205, 304, or 316 stainless steel, Hastelloy C-276, 254, SMO, carbon steels; Special materials on request.
Calibration: Calibrated for customer application
Fitting Type: Flanged, threaded, hub or weld-end standard; Others on request.
Head Loss: Varies with beta ratio and DP
Installation Requirement: Upstream 3D, Downstream 0.5D
Line size: 0.5 to 120″ or larger
Pressure Range: Up to 20,000 psi (1,380 bar)
Repeatability: ±0.1%
Standard Beta Ratios: 0.15 to 0.90, special betas available
Temperature Range: Up to 1,600 °F (870°C)
